A single swing gate assembly with 3-inch by 3-inch steel structural tube posts capped internally and anchored via 8-inch by 8-inch by 5/8-inch aluminum base plates with 11/16-inch diameter holes. The gate framing consists of 3-inch by 2-inch gate frames with aluminum 2-1/2-inch by 2-1/2-inch by 1/4-inch panel framing typical, supporting Trex Transcend infill slats. Hardware includes gate hinges, a gate latch, and optional lockable drop rods set above grade.
ELEVATION VIEW PLAN VIEW 2"± 5'-10" 6'-0" VARIES GRADE 1/2" EQ 1" EQ 1/2" LOCKABLE DROP RODS (OPTIONAL) 3" X 2" GATE FRAME ALUM L 2 1/2" X 2 1/2" X 1/4" PANEL FRAMING TYP. TREX TRANSCEND INFILL SLATS STEEL TS 3" X 3" POST CAPPED INSIDE STEEL TS 3" X 3" POST CAPPED INSIDE 8" X 8" X 5/8" ALUM BASE PLATE W/ 11/16"Ø HOLES GATE LATCH GATE POST GATE POST HINGES
