A-GTC6T — Wall Deflection Joint

Architectural · A-GTC6T

Wall Deflection Joint

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: A508
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Bracing Expansion / Control Joints Partitions Walls

Connections

Bracing Connection Expansion / Slip Connection

Text on the drawing

600S162-33 METAL STUDS @ 24" OC 5/8" TYPE 'X' GB BOTH SIDES CONT METAL STUD AND TRACK SPACER 600T125-33 CONT METAL TRACK WALL BRACE: 600S162-33 @ 24" OC (4) #12 TEK SCREWS
