Architectural · A-GR5T9

Existing Piping and Handrail Removal at Industrial Facility

Elements

Columns Railings / Guards Floors / Slabs

About this detail

An industrial facility photograph outlines demolition scopes including the removal of existing four-inch caustic soda container piping with elbows, existing handrails, and cogeneration conduit and cables. Callouts direct the removal of caustic piping to designated existing joints near column A-6. The view captures structural concrete columns, framing, and infill slab locations between grid lines 4 and 6, and A and C.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
