A laminated glazing unit is held within a steel glass shoe with stainless steel shoe cladding at the head condition. The glass shoe connects to secondary steel as required via bolted connections. Surrounding wall assemblies and insulation tie into the structural framing above the glazing line.
EM-5 SECONDARY STEEL AS REQUIRED LAMINATED GLAZING UNIT STEEL GLASS SHOE STAINLESS STEEL SHOE CLADDING
