A hollow metal frame connects to a continuous steel runner at the partition head. Lateral bracing is positioned above the frame within the stud cavity. Gypsum wallboard layers terminate at the hollow metal frame per the specified partition type.
SEE PARTITION TYPE FOR VARYING CONDITIONS 1 15/16" 1 9/16" VARIES PARTITION TYPE VARIES WITH 2" 5/8" 09 2216 LATERAL BRACING 09 2216 CONTINUOUS STEEL RUNNER 08 1113 HM FRAME
