A retractable ladder in the closed position mounts to a wall assembly constructed of one-eighth-inch aluminum 6061-T6 material. Fasteners secure the ladder bracket through the wall finish, requiring backing at all attachment points typically. The wall layout includes scheduled partitions aligned with the interior framing.
MAT'L: 1/8" ALUM 6061-T6 PROVIDE BACKING AT ALL ATTACHMENT POINTS, TYP LINE OF WALL SCHED PTN 3/4" 3/4" RETRACTABLE LADDER LADDR IN CLOSED POSITION » i l Z. C + -T> <: T T -
