An open two-post data and communication rack stands eighty-four inches tall with horizontal wire management and vertical single duct wire management. The upper half of the rack accommodates forty-eight port category six patch panels with white and blue jacks. An owner-provided server sits on a provided shelf in the lower section of the frame. The entire assembly is mechanically fastened to the floor at a minimum of four locations.
