A heavy-duty chainlink gate is mounted between terminal posts extending down to concrete footings. The gate frame includes a center brace and a 1-5/8" by 1-1/4" brace rail located at the base only. Heavy-duty hinges secure the gate leaf to the supporting post, while a lockable latch secures the closing edge. A tension wire runs along the top of the fence fabric, maintaining a top of fence elevation of plus 6'-0" relative to finished grade at plus 0'-0".
HEAVY DUTY HINGE TENSION WIRE AT TOP OF FENCE FABRIC LOCKABLE LATCH CENTER BRACE BRACE RAIL 1 5/8"X1 1/4" AT BASE ONLY FIN. GRADE +0'-0" T.O. FENCE +6'-0"
