A channel stringer connects to a concrete slab per stair manufacturer design with a maximum seven-inch rise and eleven-inch run. Stair treads feature diamond-shaped openings with serrated edges attached to the stringer. A steel railing mounts adjacent to the stair assembly.
CHANNEL STRINGER PER STAIR MANUFACTURER STAIR TREADS, DIAMOND-SHAPED OPENING WITH SERRATED EDGES PER STAIR MANUFACTURER CONCRETE SLAB PER PLAN STEEL RAILING PER STAIR MANUFACTURER STRINGER ANCHORING DETAIL PER STAIR MANUFACTURER DESIGN TREAD AND STRINGER ATTACHMENT PER STAIR MANUFACTURER DESIGN MAX 11" 3/4" MAX 7"
