This non-rated partition assembly incorporates batt insulation as specified in the partition schedule. The top of the partition detail coordinates with an adjacent cold box where required by the floor plan. Interior elevations govern the precise positioning and height.
NON-RATED PARTITION - REFER TO PARTITION SCHEDULE BATT INSULATION - REFER TO PARTITION SCHEDULE SEE INTERIOR ELEVATION COLD BOX (WHERE OCCURS)
