An accessible parking sign assembly includes a main parking only panel with the international symbol of accessibility, accompanied by auxiliary panels for minimum fine and van accessible designations. The sign is located at the end of the stall at the centerline, mounted on a post at eighty inches above finished grade to the bottom of the sign. Alternatively, wall-mounted or planter-mounted installations are positioned at thirty-six inches above finished grade to the bottom of the sign. The installation is provided at all accessible parking stalls in accordance with the site plan.
