A four-drawer base cabinet is supported by a pressure-treated wood base frame cut to height and leveled with shims as required. A plywood substrate carries the simulated stone countertop above the cabinet box unless noted otherwise. The drawer faces feature a medium-density fiberboard core with a wood veneer finish. Overall vertical dimensions indicate a maximum height of thirty-four inches and a minimum of thirty-three and three-quarter inches with equal drawer spacing.
SIM. STONE COUNTER TOP, UON 2 X PT WOOD BASE FRAME CUT TO HEIGHT OF BASE SHIM BASE AS REQUIRED TO LEVEL PLYWOOD SUBSTRATE A875.1 7 A875.1 8 MDF CORE DRAWER _ WD VENEER FINISH, UON A875.1 9 EQ 34" MAX 33.75" MIN EQ A875.0 1 1/2" = 1'-0" BASE CABINET W/ 4 DRAWERS (D) 3
