Reinforcement configuration at a concrete wall corner utilizes number five reinforcing bars spaced at twelve inches on center throughout the wall legs. A corner bar configuration provides two number five bars at the terminus of the wall leg. Wall thickness is designated as t, with dimensions and panel elevations referenced per plan.
