A hollow metal fully welded frame connects to a partition header assembly with continuous 5/8-inch non-hardening resilient sealant applied on both sides where the frame meets the finished opening wall. The partition framing extends above the header assembly, and a sidelight glazed unit inserts into the lower frame profile.
HEADER ASSEMBLY; S.S.D. HOLLOW METAL FULLY WELDED FRAME; SEE DOOR SCHEDULE B SIDELIGHT HEAD (JAMB AT WALL SIM.) 2" TYP. 5/8" CONT. NON-HARDENING RESILIENT SEALANT WHERE FRAME MEETS F.O. WALL, TYP., BOTH SIDES PARTITION; SEE PLANS FOR LOCATIONS AND PARTITION SCHEDULE FOR ASSEMBLY
