This interior storefront sill detail features an aluminum framing system with a mullion set atop a concrete structural slab and concrete topping slab. The assembly incorporates one-quarter-inch laminated storefront glazing secured within the frame, complemented by J-molds on both sides typically. Fire caulking is applied to both sides of the sill junction. A floor finish per schedule is indicated, with tenant-determined finishes noted as not in contract.
'J' MOLD - BOTH SIDES, TYP. MULLION BEYOND 1/4" LAMINATED STOREFRONT GLAZING CAFE ENTRYWAY FIRE CAULKING - BOTH SIDES, TYP. 1 3/4" BOTH SIDES 1/4" TYP. MULLION CONCRETE TOPPING SLAB FLOOR FINISH PER SCHEDULE, WHERE FLOOR FINISH (N.I.C.) TBD BY TENANT CONCRETE STRUCTURAL SLAB 6"
