This stair detail shows concrete-filled metal pan treads with a maximum riser height of seven inches. The stair stringer incorporates formed steel supports with dimensions of one inch and three inches at the landing junction. A handrail attachment connects directly to the top landing slab edge with a vertical post and mounting plate. Additional dimensional clearances of two inches and three inches govern the top landing interface.
