This wall section details a glass fiber reinforced concrete panel assembly featuring a nine-inch dimensioned joint with continuous backer rod and sealant. The cavity is filled with R-19 batt insulation behind the glass fiber reinforced concrete panel, which includes an integrated reveal and transitions to glass tile.
9" CON'T. BACKER ROD AND SEALANT R-19 BATT INSULATION GFRC PANEL GFRC REVEAL AT GLASS TILE TO GFRC TRANSITION 11 A8.11
