A-G8TPS — EW2

Architectural · A-G8TPS

EW2

Units: imperial
Sheet: A6.01
Discipline: Architectural

Materials

Brick Cold-formed Steel Gypsum / Drywall Masonry / CMU Metal (misc.)Timber / Wood

Elements

Facades / Cladding Insulation Walls Waterproofing / Flashing

Text on the drawing

EW2 5/8" TYPE X GWB 6" MTL STUD FRAMING PER STRUCTURAL BATT INSULATION (BRICK RAINSCREEN, TYP)
