An air handling unit assembly comprises an electric duct heater, a direct expansion cooling coil, an access door, and a backflow damper positioned within the main housing. A downstream duct transition connects to the unit housing. The base frame attachment to the tower floor structure is referenced to a separate detail.
ELECTRIC DUCT HEATER DX COOLING COIL ACCESS DOOR BACKFLOW DAMPER DOWNSTREAM DUCT TRANSITION SEE VIEW 1/3.M-536 FOR AHU BASE FRAME ATTACHMENT TO TOWER FLOOR STRUCTURE
