A heavy-duty 15/16-inch T-rail connects directly through the grid to a wood backer using screws. Black fiber felt is installed underneath the wood backer as a layer in the assembly.
WOOD BACKER BLACK FIBER FELT HEAVY DUTY 15/16" T-RAIL DIRECT SCREW CONNECTION THROUGH GRID TO WOOD BACKER
