A-G6RQ2 — Head Dtl - Mtl Deck: Typ Parallel

Architectural · A-G6RQ2

Head Dtl - Mtl Deck: Typ Parallel

Scale: 3" = 1'-0"
Units: imperial
Sheet: A-801
Discipline: Architectural

Materials

Cold-formed Steel Concrete Metal (misc.)Steel

Elements

Anchors / Embeds Connections / Plates Decks Floors / Slabs Insulation Partitions Walls

Connections

Bolted Connection Deck Attachment Embed Plate

Text on the drawing

HEAD TRACK (NON-SLOTTED) CONCRETE DECK, FLUTES PARALLEL TO PARTITION 3" WIDE 3/16" ST PL TO SPAN O/ THREE FLUTES AT 12" OC: FASTEN TO CONC DECK W/ (3) PAIRS OF #12 SMS FILL FLUTE W/ MINERAL WOOL INSULATION, 4PCF
