A structural pipe support sits centered on a walk pad membrane atop the roofing system. The base plate maintains a minimum four-inch clearance from the edges of the walk pad. The walk pad membrane is fully welded to the underlying roof. The support assembly features threaded vertical posts carrying a horizontal framing channel for utility or piping runs.
WALK PAD MEMBRANE - FULLY WELDED TO ROOF PIPE SUPPORT ROOFING SYSTEM 4" MIN. 4" MIN.
