Medium style storefront door assembly showing framing layout, threshold clearances, and height dimensions. Vertical dimensions indicate a ten-inch bottom rail and a forty-two-inch latch or rail height. Detail reference bubbles point to sheet AD-3 for adjacent conditions.
