A-G3BSC — Exterior Door Threshold

Architectural · A-G3BSC

Exterior Door Threshold

Scale: SCALE: 6" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Elements

Doors Drainage Entrances Waterproofing / Flashing

Text on the drawing

MATCH DOOR JAMB WIDTH ALIGN WITH AND 1 1/2" 1 1/2" 1/4" STONE THRESHOLD SEE FINISH PLAN SEE FINISH PLAN ENTRY DOOR DOOR SWEEP SEE DOOR HARDWARE CAULKING COMPRESSION JOINT

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
