An aluminum curtain wall system intersects a concrete over metal deck floor slab supported by a steel beam at the second floor elevation of 15'-0". Perimeter firesafing with a metal angle is installed at the slab edge behind the curtain wall. A pre-finished spandrel panel is integrated into the curtain wall assembly. A pre-finished aluminum fin matching the curtain wall is attached on the exterior face.
N 2ND FLOOR 15'-0" EXTERIOR INTERIOR PRE-FINISHED ALUMINUM FIN TO MATCH CURTAIN WALL STEEL BEAM CONCRETE OVER METAL DECK PERIMETER FIRESAFING WITH METAL ANGLE PRE-FINISHED SPANDREL PANEL ALUMINUM CURTAIN WALL SYSTEM AG12.4 9 AG12.4 12 SIM.
