A stainless steel roundbar extends beyond a structural angle below, anchored by a stainless steel eyebolt and fastener assembly per shop drawings. A stainless steel metal fabric covers the assembly, aligned with a 3-inch offset from centerline and a 6-inch dimension point. Dimensions include a 6-inch vertical clearance and 1/2-inch spacing.
FOS SS METAL FABRIC SS ROUNDBAR BEYOND STRUCTURAL ANGLE BELOW 6" SS EYEBOLT AND FASTENER ASSEMBLY PER SHOP DRAWINGS 3" 1/2" 6" DIM POINT FOS F E D C
