Architectural · A-FYG5M

Mop Sink with Broom Rack

Materials

Elements

Walls Floors / Slabs Connections / Plates

About this detail

An interior architectural installation of a mop sink and broom rack includes corresponding plan and axonometric views. The wall assembly incorporates wood or metal stud framing with a concealed backing plate fastened at every stud, coordinated with wall finishes and flooring per architectural plans. A galvanized steel mounting bracket and assembly by the manufacturer supports the fixtures. Vertical and horizontal clearances are dimensioned including alcove depths, knee clearances, and spout heights, along with optional bottle filling stations coordinated per plumbing drawings.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
