A-FXD8S — ADA Clearance Requirements

Architectural · A-FXD8S

ADA Clearance Requirements

About this detail

This drawing outlines accessible design clearances and mounting heights for plumbing fixtures, grab bars, and accessories. It details adult and children drinking fountain elevations, plan configurations, knee and toe space dimensions, and maximum spout heights. Urinal rim heights, water closet clearances, grab bar placements, and toilet paper dispenser locations are dimensioned. Lavatory mounting heights, mirror bottom edge requirements, and exposed pipe insulation dimensions are also specified alongside accessibility notes.
