Wood casing matching existing conditions is fitted around the opening with shims as required within the existing partition. A five-eighths inch door stop is secured to the head frame above the reverse swing door. The entire assembly sits within the existing masonry opening with dimensions verified in field.
WOOD CASING TO MATCH (E) (E) DOOR REVERSE SWING, SEE FLR PLAN SHIM AS REQ'D IN (E) PARTITION 5/8" DOOR STOP (E) MASONRY, V.I.F.
