A steel stair railing transition assembly at a stair landing consists of 1-1/4 inch nominal diameter steel pipe horizontal railings, handrails, and vertical posts. The vertical posts are supported by 5/8 inch diameter steel bar support brackets located at each post. A minimum 3/8 inch steel plate spans between the steel stringers at stair landings. All stair railing connections and intersections are welded and ground smooth.
DP 1 1/2" UON 3 1/2" 11" TREAD, UON 2 1/2" 1" LINE OF STAIR NOSING, WHERE OCCURS 1-1/4" NOM DIA STEEL PIPE HORIZ RAILINGS 1-1/4" NOM DIA, STEEL PIPE HANDRAIL 1-1/4" NOM DIA STEEL PIPE VERT POSTS 5/8" DIA STEEL BAR SUPPORT BRACKET AT EACH VERT POST LINE OF STAIR NOSING, WHERE OCCURS LINE OF STEEL STRINGERS MIN 3/8" STEEL PLATE BETWEEN STRINGERS @ STAIR LANDINGS NOTE: WELD & GRIND SMOOTH EACH STAIR RAILING CONNECTION & INTERSECTION 2" 5 5/32" R±5"
