Suspended gypsum board ceiling construction supported by wire ceiling hangers tied to a main suspension system. The grid layout carries gypsum board panels joined at reveals. Wire hangers connect overhead structural supports to the ceiling runners.
09 51 13.G00 CLG HANGER 09 51 13.B00 SUSPENSION SYSTEM 09 51 13.B00 SUSPENSION SYSTEM 09 51 13.G00 CLG HANGER 09 51 13.G00 CLG HANGER 09 51 13.B00 SUSPENSION SYSTEM 09 51 13.B00 SUSPENSION SYSTEM 09 51 13.G00 CLG HANGER
