The plan view details handrail extensions composed of one and a half inch outside diameter brushed stainless steel pipe rail welded to vertical supports. A one inch outside diameter steel pipe sleeve connects the assembly. Painted steel pipe supports are shown dashed within the layout, incorporating six inch dimensional spacings and a three inch radius curve.
SCALE: HANDRAIL EXTENSIONS 1" = 1'-0" 6" 6" STEEL PIPE SUPPORTS SHOWN DASHED PLAN VIEW PAINTED 1 12 " O.D. BRUSHED STAINLESS STEEL PIPE RAIL WELDED TO VERTICAL SUPPORTS 1" O.D. STEEL PIPE SLEEVE PAINTED 1 12 " O.D. STEEL PIPE RAIL WELDED TO VERTICAL SUPPORTS 13
