An exterior glazing and metal panel junction features an aluminum finish accent bar crossing adjacent vertical mullions. A four-sided structural silicone glazed joint aligns horizontally across the assembly with specified dimensional clearances. Mullions extend beyond the joint with detailed profile dimensions.
F11 247' - 6" 1 3 / 4 " ALUMINUM FIN ACCENT BAR 2 " 1 3 / 8 " 1 5 / 1 6 " 2 1 / 1 6 " 3 " 3 " MULLION BEYOND MULLION BEYOND EDGE OF 4 SIDED SSG JT 3" = 1'-0" C2 ELEV DTL @NORTH STAIR SLAB
