A one-and-a-half-inch diameter galvanized steel rail mounts to a wall or post via one-and-a-half-inch square vertical supports and metal brackets spaced at five feet on center with welded connections. The handrail maintains a two-and-eleven-inch clearance above the stair nosing or landing and provides a one-and-a-half-inch clearance from the wall face. At terminal ends, the handrail returns back to the wall or post. The centerline of the rail sits two and a quarter inches from the wall surface.
1 1/2" SQ. VERT. SUPPORTS METAL BRACKET @5'-0"o/c w/WELDED CONNECTION RETURN HANDRAIL TO WALL/POST AT ENDS TYP. 1 1/2" DIA. GALV. STEEL RAIL, SEE PLAN WHERE OCCURS C L 2 1/4" CLR. 1 1/2" 1/4" 2'-11" ABOVE STAIR NOSING/ LANDING CLR. 1 1/2"
