An accessible shower stall rear wall detailing the mounting heights and clearances for plumbing fixtures and accessories. The fold-down seat is mounted at a height between 17" and 19" from the finished floor. The grab bar is positioned at a height ranging from 33" to 36" with an 18" clearance dimension.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
