An elevator car door and sill interface with a hollow metal frame grouted solid. The frame mounts to a partition system utilizing three frame clips per jamb. Sealant applies at the frame-to-partition joint with a half-inch setback and a two-inch vertical dimension.
DOOR LINE OF CAR FRAME (GROUT SOLID) SEALANT FRAME CLIP (3 PER JAMB) PARTITION SYSTEM 2" 1/2" SILL
