Concrete tilt-up wall panels meet at a corner with a half-inch vertical joint between them. A backer rod is installed at each face of the joint with continuous sealant running from the footing to the top of the panel and across the half-inch joint. Three-quarter-inch chamfers are detailed at the exterior concrete corners typical throughout the assembly.
CONC. TILT- UP WALL PANEL BACKER ROD AT EACH FACE WITH CONTINUOUS SEALANT FROM FOOTING TO TOP OF PANEL AND ACROSS 1/2" PANEL JOINT TYPICAL 1/2" 3/4" CHAMFER TYPICAL
