Architectural · A-FR5AN

Guardrail and Handrail Assembly at Stair

Materials

Steel Stainless Steel Timber / Wood

Elements

Columns Stairs Railings / Guards Floors / Slabs Connections / Plates Reinforcing

Connections

HSS Connection Welded Connection

About this detail

An upper stainless-steel diameter one and a half inch handrail with a number four finish mounts on a half-inch painted steel rail bracket above a matched guardrail. A carbon steel three-by-three-inch six-gauge welded wire mesh panel is framed by one-inch by three-quarters-inch by zero-point-one-two-five-inch interior steel angles and zero-point-five-inch by zero-point-one-two-five-inch exterior flat bars with mitered and ground-smooth welded corners. A one-and-a-half-inch by three-eighths-inch shaped steel plate welds to the hollow structural section below with half-inch steel plate spacers at each guardrail support. The entire assembly anchors to three-quarter-inch IPE wood treads with a satin finish and a half-inch prefinished round nosing profile over a fourteen-by-four hollow structural section support.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
