This plan detail shows the exterior curtain wall jamb support interfacing with adjacent wall construction. The aluminum curtain wall framing ties back to a structural steel angle anchored at the rough opening. Weather resistive barriers, metal flashing, and sealant joints maintain the thermal and moisture envelope. Interior gypsum wallboard finishes the perimeter condition.
NOM. OPENING 07 SEA.01 08 STR.01 07 FLA.03 07 MTL.01 05 GRT 07 WRB.05 07 WRB.01 09 GWB.03 09 GWB.01 + 0' - 0 1/2" R.O. 0' - 0 1/4" 0' - 7" 0' - 1 3/4"
