A stainless steel angle is anchored to a concrete substrate with anchor bolts spaced at twenty-four inches on center. A grout depth is maintained as required with typical one-eighth inch clearances. The assembly aligns with adjacent concrete pours and maintains specific vertical dimensions of one and one-eighth inches and seven-eighths inches.
1/8" TYP. 1/8" ALIGN 1 1/8" 7/8" 2" SECTION A ALIGN GROUT, DEPTH REQUIRED - BOLTED EVERY 24" O.C., TYP.
