A four-sided structural silicone glazing joint is located at the stack joint of an aluminum curtain wall mullion. An exterior aluminum fin projects from the centerline of the mullion, aligned with vertical and horizontal framing components. Dimensions indicate a typical 1-3/4 inch stack joint clearance with precise alignment tolerances across the framing members.
1 3 / 1 6 " 1 / 2 " 1 9 / 3 2 " 2 5 / 3 2 " 3 / 8 " 1 ' - 6 " 5 1 / 1 6 " F36 591' - 0" MULLION BEYOND EDGE OF 4 SIDED SSG JT OF STACK JOINT OF MULLION 3 " 1 / 4 " 1 3 / 3 2 " 1 1 1 / 1 6 " 1 3 / 3 2 " 1 / 4 " T Y P . 1 3 / 4 " MULLION BEYOND ALUMINUM FIN ALUMINUM FIN
