Architectural · A-FPDY7

Typ. Artglass Detail

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: A4
Discipline: Architectural

Materials

Glass / Glazing

Text on the drawing

C A B TYP. 1/4" TYP. 1/2" 1/2" 1" TYP. 1/2" TYP. 1" TYP. 1"
