This plan detail shows the intersection of a tile finish meeting a metal portal at an exterior or interior corner. The assembly consists of framing, backing layers, and finish materials tied together with mechanical fasteners. The tile is set directly against the adjacent wall construction with appropriate corner trims and sealant joints. Clearances and alignment are maintained to provide a clean transition between the dissimilar materials at the corner junction.
