A thirty by thirty inch vinyl sign features screen printed text and artwork laminated between two panels. Each sign carries a unique graphic with locations determined and field verified. The assembly is secured to the wall using expansion bolts at each corner. All corners feature a one half inch radius.
2' - 6" 2' - 6" 30" x 30" VINYL SIGN WITH SCREEN PRINTED TEXT AND ARTWORK (GRAPHICS TO BE DIGITALLY PROVIDED BY ARCHITECT). LAMINATED BETWEEN TWO PANELS AND WALL MOUNTED. EACH SIGN TO BE A DIFFERENT GRAPHIC. LOCATIONS TO BE DETERMINED AND FIELD VERIFIED. MOUNT TO WALL WITH EXPANSION BOLTS AT EACH CORNER. CORNERS TO HAVE A 1/2" RADIUS. D5 A660
