Horizontal brace beams frame into a column and girder per plan with skewed connections detailed per 4/3.S-510. Stiffener plates are welded to the assembly with a quarter-inch fillet weld and centered on grid Y per detail 2/3.S-510. Diagonal bracing members connect via gusset plates and bolts.
14 Y GIRDER PER PLAN 1/2" 1/2" 1/2" 1 1/2" BEAM PER PLAN 2 3.S-513 HORZ BRACE BEAM PER PLAN HORZ BRACE BEAM PER PLAN 1/4 SKEWED CONN PER 4/3.S-510, TYP COL PER PLAN 1' - 0" STIFFENER PER 2/3.S-510, CENTER ON GRID Y
