Handrail and guide rail details feature gravity-stationed assemblies without mechanical fasteners, standing thirty-four to thirty-eight inches high. Guide curbs provide a minimum four-inch high continuous barrier along the edge with twelve-inch minimum clearances. Handrails are coordinated per architectural plans.
34" TO 38" 4" MIN. HIGH TO SUIT DESIGN < 4" 34" TO 38" 12" MIN. 12" MIN. (C) GUIDE CURB GUIDE DETAIL (A) HANDRAIL AND GUIDERAIL GUIDE RAIL DETAIL HANDRAIL 4" MIN. HIGH CONTINUOUS GUIDE CURB HANDRAILS PER ARCHITECTURAL PLANS GRAVITY STATIONED, NO FASTENERS
