A two-piece stainless steel column coverplate is secured with countersunk stainless steel fasteners within a column base assembly. The assembly incorporates an L-profile steel frame with a typical two-inch clearance and specific dimensioning for alignment and joint spacing.
SECTION B FF RWL, SSD BASE BEYOND 2 PIECE STAINLESS STEEL COLUMN COVERPLATE COUNTERSUNK STAINLESS STEEL FASTENER L-PROFILE STEEL FRAME 4 1/4" 1/4" 1/4" 1" TYP. 2" CLR 7/16" 7/16" 3/32" TYP. 1 1/2"
