A one-inch wood trim cap sits atop fire-treated wood blocking and a metal stud wall, with a half-round trim piece applied if the cap cannot be sloped. Gypsum wallboard extends three-eighths of an inch beyond the framing face to align with the carpet edge. Wall carpet is rolled over the top of the wallboard and stapled to the blocking prior to attaching the wall cap. Flat wall carpet covers the exterior faces of the gypsum board.
1X WOOD TRIM CAP PAINT PER ELEVATIONS. FIRE TREATED WOOD BLOCKING WALL CARPET 3/4" OVERHANG GWB 3/8" TO ALIGN WITH FACE OF WALL CAPRET ROLL WALL CARPET OVER TOP OF WALLBOARD AND STAPLE TO BLOCKING BEFORE ATTACHING WALL CAP. TOP CAPS THAT CAN NOT BE SLOPED TO HAVE HALF ROUND TRIM CL
