A prefinished metal drip edge transitions into prefinished metal decking at the base of the assembly. The flashing is secured against a vertical hollow structural section member using threaded fasteners with washers. The horizontal top leg extends upward behind the break in the decking profile.
PREFINISHED METAL DRIP EDGE PREFINISHED METAL DECKING 6" = 1'-0" A130 5 TYPICAL BASE FLASHING
