Directly adhered PVC membrane roofing is installed over insulation and a metal deck with a specified seam overlap dimension. An aluminum tape per manufacturer requirements is applied over the membrane seam junction.
ALUMINUM TAPE RF1 PER MANUF. OVER LAP DIMENSION PVC MEMBRANE ROOFING, DIRECTLY ADHERED
